Electric Experiments for Technology, 2nd Edition ISBN: 978-1-935422-12-9
** PLEASE DESCRIBE THIS IMAGE **

* Electrical Resistance and the Resistor
* Flashlight Circuit Measurement and Simulation
* LTspice Simulation of the Flashlight Circuit * Power Supplies and Batteries
* Voltage, Current, and Power * Analog "D'Arsonval" Meter
* DC Measurements and Meter Loading * LTspice Circuit Simulation
* Kirchhoff's Voltage and Current Laws * Potentiometer Voltage Dividers
* Thevenin's Theorem and the Bridge Circuit * Transistor / Dependent Current Source
* Mesh Current Analysis * Node Voltage Analysis * 15 Network Theorems
* Superposition and the Voltage Translator * Function Generator and Oscilloscope
* RC Transient Response * RL Transient Response * Capacitor Network Transient Response
* Superposition of AC and DC Voltages * AC Measurements / Series RC Circuit
* AC Measurements / Series RL Circuit / Series-Parallel * Capacitive Voltage Dividers
* Two-Source AC Circuit * Thevenin's and Norton's Theorems
* DC Motor and Generator Basics * 2-Phase Power Distribution
* Power Factor Compensation / Parallel Circuit / Series / Power Transfer
* Low-Pass Filters * High-Pass Filters * Audio Crossover Network
* Two-Pole Low-Pass and Band-Pass Filters * Series Resonant Passive Band-Pass Filter
* Parallel Resonant Band-Pass Filter * Audio Output Transformer
* Three Phase Power / Wye Connection / Delta Connection * Fourier Series Analysis
* Band-Pass Filter / FFT / Square Wave / Triangle Wave

Appendix

* Electric Circuits Lab Report Information * Phase Tripler Circuit Information
* DC Motor-Generator Information * Flashlight Circuit Information * LTspice Information

Lab 1: Electrical Resistance and the Resistor
Lab 7: DC Measurements,Loading Effects, Simulation
Lab 15: Network Theorems
Lab 19: RL Transient Response
Lab 41: 3-Phase Power / Wye Connection
Lab 44: Bandpass Filter / FFT / Square Wave
Experiments with 3-Phase
